Luigi Moreschi Motorsport srl
Motore in vendita - Engine for sale

Toyota

Marca
Make

Toyota TOM's

Modello
Model

Formula 3 - 3S-GE
Cilindrata
Cylinder capacity
1998 Cm3
121.93 Inc3
N° Cilindri
n° cylinders
4 Corsa
Stroke
86,00 mm
3,306 inc
Alesaggio
Bore
86,00 mm
3,306 inc
Anno
Year
31/7/1992 Disposizione
Configuation
In linea
In-line
N° Valvole tot
Total n of valves
16 Valvole/Cil.
Valves/Cyl.
4
Tipo di ciclo
Engine cycle
4 Tempi
4 Stroke
Potenza
Power
172 KW
230 Hp
Alberi a camme
N of cammes
2 Tipo FIA
FIA Type
STR 4 DOHC
Info
TOM's fu fondata nel 1974 e iniziò la sua attività come officina specializzata in tuning per auto Toyota; nel 1983 istituì un proprio reparto competizioni, sempre con base Toyota. Il primo approccio di TOM's alla F3 avvenne nel 1981; quando iniziarono a elaborare motori Toyota per il campionato giapponese di F3, dove ottennero un successo quasi immediato. Nel 1987 TOM's aprì una sede a Norfolk, in Inghilterra, e iniziò a sviluppare il proprio motore Toyota F3 per il mercato europeo.

Questo motore Toyota 3S-GE da 2,0 lt., sviluppato dagli ingegneri Yamaha; è stato prodotto in Giappone nel 1991 per essere installato su una Celica 2.0 GT-i 16; e modificato nel 1992 da TOM's per la nuove vetture 032F del '92 e 033F del '93.
Motore super quadro utilizzato per la Formula 3 negli anni '90; revisionato e modificato con l'installazione di carburatori Weber 48 DCO in UK, nel 2019, per l'utilizzo su un prototipo; con 2 gare di utilizzo. Acquistato dall'attuale proprietario nello stesso anno per prove libere su una Ralt Formula 3, ma non utilizzato.
Completo di centralina accensione; volano piccolo con corona e motorino d'avviamento posteriore per cambi Hewland.

Info.

TOM's was founded in 1974 and started out as a Toyota tuning shop; in 1983 it set up its own competition division, also based on Toyota. TOM's first foray into F3 came in 1981; when they began developing Toyota engines for the Japanese F3 championship, where they achieved almost immediate success. In 1987 TOM's opened a facility in Norfolk, England, and began developing their own Toyota F3 engine for the European market.

This 2.0-liter Toyota 3S-GE engine, developed by Yamaha engineers; was produced in Japan in 1991 for use in a Celica 2.0 GT-i 16; and modified in 1992 by TOM's for the new '92 032F and '93 033F cars.
Super square engine used in Formula 3 in the 1990s; overhauled and modified with Weber 48 DCO carburetors in the UK, in 2019, for use on a prototype; with 2 races. Purchased by the current owner in the same year for free practice on a Ralt Formula 3, but not used.
Complete with ignition control unit; small flywheel with crown and rear starter motor for Hewland gearboxes.
Condizioni
Conditions
metà chilometraggio Prezzo
Price
9'000,00
